3D Compactor

[:he]מערכת תלת ממדית לשילטה בעבודה דחיסה. המערכת הינה Trimble CCS900 מספקת שליטה על דחיסה ויכולות תיעוד, כולל:

  • מדידה של חומר הדחיסה כאינדיקציה לנוקשות וצפיפות החומר
  • תצוגה בזמן אמת של מדידת הדחיסה, ספירת מעבר והנחיות למפעיל
  • מיפוי והקלטה של הדחיסה ומידע על מצב קיים של החומר בשטח

Trimble CCS900 Compaction Control System provides compaction control and documentation capabilities, including:

  • Measurement of material compaction as an indication of material stiffness or density
  • Real-time display of compaction measurements, pass counts, and guidance to the operator
  • Mapping and recording of compaction and as-built material surface data

[:he]

Compaction control systems have been prevalent in Europe for many years. The technology is gaining momentum in North America and Asia-Pacific regions due to contactor requirements for better in-field validation of compaction results, improvements in GPS-based machine control technology, and increased documentation requirements for government projects and warranty work.

  • Fully portable, rugged on-machine components, interoperable between other Trimble compaction or grade control systems
  • Records and displays color coded number of passes
  • Compaction to operator defined layered lifts
  • Cut/Fill mapping and thickness monitoring for real-time QA/QC capabilities in the cab of the machine
  • As-built mapping and recording of final compacted surface for analysis of compaction progress and volume calculations in the office
  • Configurable GPS modes depending upon application and available jobsite site infrastructure:
    • RTK – centimeter-level positioning
    • SBAS (WAAS/EGNOS/MSAS) – sub-meter level positioning
  • Records and displays compaction meter values (CMV)
  • Records and displays resonance meter value (RMV) or drum decoupling or double jump
  • Display of vibratory frequency, amplitude, and compactor speed
  • Proofing mode for final compaction runs and compaction statistical reports listed level of design compaction over or under-achieved and target met
  • On-board recording of compaction data for analysis and archival back in the office.
  • Two-way wireless data transfer of compaction and machine productivity data to and from the office to machine





SITECH, Machine Control:  מערכת לשליטה על כלים לייעול של של זמן, עלויות ודיוק

חברת Axis מציעה ציוד מדידה איכותי, מחפשת מכשיר מדידה שמתאים לצורכי מודד שטח. אצלנו תמצאו מגוון מכשירי מדידה למודדים וקבלנים, מערכות מידע גיאוגרפיות, כלים למיפוי, מכשירי ניווט, מיפוי אווירי, פוטוגרמטריה, פתרון לתצלומי אוויר,בתימטריה ופתרונות נוספים.

אצלנו תוכלו למצוא בין היתר: מכשירי GPS וקלטות, מערכות GIS, סורקי לייזר, רחפנים ותוכנות לעיבוד ענן נקודות, דיסטומטים (מד קואורדינטות), מיפוי בעזרת מציאות רבודה, כלים למיפוי ימי, מיפוי נע, מערכות שליטה על כלים, ניטור, תפרונות מיקום מתקדמים, רשת VRS, מאזנות אופטיות ולייזר ועוד.[:en]

Compaction control systems have been prevalent in Europe for many years. The technology is gaining momentum in North America and Asia-Pacific regions due to contactor requirements for better in-field validation of compaction results, improvements in GPS-based machine control technology, and increased documentation requirements for government projects and warranty work.

  • Fully portable, rugged on-machine components, interoperable between other Trimble compaction or grade control systems
  • Records and displays color coded number of passes
  • Compaction to operator defined layered lifts
  • Cut/Fill mapping and thickness monitoring for real-time QA/QC capabilities in the cab of the machine
  • As-built mapping and recording of final compacted surface for analysis of compaction progress and volume calculations in the office
  • Configurable GPS modes depending upon application and available jobsite site infrastructure:
    • RTK – centimeter-level positioning
    • SBAS (WAAS/EGNOS/MSAS) – sub-meter level positioning
  • Records and displays compaction meter values (CMV)
  • Records and displays resonance meter value (RMV) or drum decoupling or double jump
  • Display of vibratory frequency, amplitude, and compactor speed
  • Proofing mode for final compaction runs and compaction statistical reports listed level of design compaction over or under-achieved and target met
  • On-board recording of compaction data for analysis and archival back in the office.
  • Two-way wireless data transfer of compaction and machine productivity data to and from the office to machine

[:]
